RJ7005-00-S00-00 – MJ-MM DUAL PURPOSE (S)
Description
| SR.NO. |
PART NO. |
SW |
L |
A JIC THREAD |
ǾD1 |
B MM THREAD |
ǾD2 |
| 01 |
RJ-7005-04-S06-14 |
19.00 |
33.50 |
7/16″-20UNF |
4.40 |
M14X1.5 6g |
6.00 |
| 02 |
RJ-7005-04-S08-16 |
22.00 |
36.50 |
7/16″-20UNF |
4.40 |
M16X1.5 6g |
8.00 |
| 03 |
RJ-7005-06-S08-16 |
22.00 |
36.60 |
9/16″-18UNF |
7.50 |
M16X1.5 6g |
8.00 |
| 04 |
RJ-7005-06-S10-18 |
24.00 |
39.10 |
9/16″-18UNF |
7.50 |
M18X1.5 6g |
10.00 |
| 05 |
RJ-7005-06-S12-20 |
24.00 |
39.10 |
9/16″-18UNF |
7.50 |
M20X1.5 6g |
12.00 |
| 06 |
RJ-7005-08-S08-16 |
22.00 |
39.20 |
3/4″-16UNF |
9.90 |
M16X1.5 6g |
8.00 |
| 07 |
RJ-7005-08-S10-18 |
24.00 |
41.70 |
3/4″-16UNF |
9.90 |
M18X1.5 6g |
10.00 |
| 08 |
RJ-7005-08-S12-20 |
24.00 |
41.70 |
3/4″-16UNF |
9.90 |
M20X1.5 6g |
12.00 |
| 09 |
RJ-7005-08-S14-22 |
27.00 |
43.20 |
3/4″-16UNF |
9.90 |
M22X1.5 6g |
14.00 |
| 10 |
RJ-7005-08-S16-24 |
27.00 |
43.20 |
3/4″-16UNF |
9.90 |
M24X1.5 6g |
16.00 |
| 11 |
RJ-7005-10-S12-20 |
24.00 |
44.30 |
7/8″-14UNF |
12.30 |
M20X1.5 6g |
12.00 |
| 12 |
RJ-7005-10-S16-24 |
27.00 |
45.80 |
7/8″-14UNF |
12.30 |
M24X1.5 6g |
16.00 |
| 13 |
RJ-7005-12-S16-24 |
27.00 |
48.40 |
1-1/16″-12UN |
15.50 |
M24X1.5 6g |
16.00 |
| 14 |
RJ-7005-12-S20-30 |
36.00 |
55.40 |
1-1/16″-12UN |
15.50 |
M30X2.0 6g |
20.00 |
| 15 |
RJ-7005-12-S25-36 |
41.00 |
56.90 |
1-1/16″-12UN |
15.50 |
M36X2.0 6g |
25.00 |
| 16 |
RJ-7005-16-S30-42 |
50.00 |
61.10 |
1-5/16″-12UN |
21.40 |
M42X2.0 6g |
30.00 |
| 17 |
RJ-7005-20-S38-52 |
55.00 |
64.30 |
1-5/8″-12UN |
27.40 |
M52X2.0 6g |
38.00 |
| 18 |
RJ-7005-24-S38-52 |
55.00 |
67.50 |
1-7/8″-12UN |
33.30 |
M32X2.0 6g |
38.30 |
